| Item | HiL169-S Series | HiL169-S Series | HiL169-S Series | HiL169-S Series | HiL169-S Series |
| Pixel Pitch | P0.93mm | P1.25mm | P1.5mm | P1.8mm | P2.5 |
| Scan Mode | 1/40 Scan | 1/60 Scan | 1/48 Scan | 1/45 Scan | 1/32Scan |
| Pixel Per Sq.m | 1,137,777 Pixel | 640,000 Pixel | 409,600 Pixel | 285,204Pixel | 160000Pixel |
| Cabinet Resolution | 640*360 | 480*270 | 384*216 | 320*180 | 320*180 |
| LED Encapsulation | SMD/COB | SMD1010 | SMD1212 | SMD1515 | SMD1515 |
| Install/Maintenance | Front Serviceable | ||||
| Optional Back-up | Power Supply & Receiving Card | ||||
| Cabinet Material | Die Casting Aluminum | ||||
| Module Size(W*H) | 300*168.75mm | ||||
| Cabinet Size(W*H*D) | 600*337.5*39mm | ||||
| Refresh Rate | 3840Hz | ||||
| Color Temperature | 6500K（Adjustable） | ||||
| Gray Scale | 16bit | ||||
| Cabinet Weight | 3.5KG/Piece | ||||
| Brightness(Nits) | 500-800 | ||||
| Average Power Consumption | 100Watt/Piece | ||||
| Max Power Consumption | 200Watt/Piece | ||||
| IP Protection | IP43 | ||||
| Operating Temperature | -10°C to 40°C | ||||
| Working Voltage | 100-240Volt(50-60hz) | ||||
